Hardware Specifications Video OutputsVideo Output VGA X 1, HDMI X 1 Supported Video Resolution 1080p 60Hz Audio Input 3.5 mm Stereo Audio Jack x 1 Audio Output 3.5 mm Stereo Audio Jack x 1 USB 2.0 Port 2 USB 3.0 Port 1 AppearanceSize 32 mm x 130 mm x 130 mm Weight 0.3 kg OthersRJ-45 1GbE LAN Port 1 Power Supply Unit / Adapter 36W AC Input Power Voltage 100V to 240V AC Power Frequency 50/60 Hz, Single Phase Power Consumption* 4.76W (36ch full-load) 3.61W (Power on Idle) EnvironmentOperating Temperature-20°C to 50°C (-4°F to 122°F) Adapter Operating Temperature 0°C to 40°C (32°F to 104°F) Storage Temperature-20°C to 60°C (-4°F to 140°F) Relative Humidity 5% to 95% RH CertificationFCC Class BCE Class BBSMI Class BEN50155EN45545Warranty 3 Years Software Specifications Maximum IP cam 36 Total FPS (H.264)* 360 FPS @ 720p (1280x720), 36 Channels 160 FPS @ 1080p (1920×1080), 16 Channels 90 FPS @ 3M (2048x1536), 9 Channels 60 FPS @ 5M (2591x1944), 6 Channels Total FPS (MJPEG)* 150 FPS @ 720p (1280x720), 15 Channels 40 FPS @ 1080p (1920×1080), 4 Channels 20 FPS @ 3M (2048x1536), 2 Channels 10 FPS @ 5M (2591x1944), 1 Channel Video Compression FormatMJPEGMPEG-4H.264Audio CodecPCMADPCMG711G726AMRAACLive View / Recording Playback Snapshot Support eMap Support PTZ Control / Patrol Log Viewer NotesVisualStation throughput is tested with Axis P1347 (H.264@1280x720@10FPS).The channel numbers indicated in the Total FPS column of each resolution is the maximum number VS360HD supports for live view display. Environment & Packaging Environment RoHS Compliant Packaging ContentMain Unit X 1Quick Installation Guide X 1AC Power Adapter X 1RJ-45 LAN Cable X 1VESA mounting kit
